F722 32-bit 50A AIO Dual BEC 2-6S Flight Control Flying Machine Flight Control ESC Integrated FPV Drone

Product features:

1. The PCB uses high-end 8-layer 2oZ thickened copper skin, applies high-end resin plugged hole PCB production technology, and has a double pad design, which has stronger over-current capability and good heat dissipation.

2. MOS adopts imported 40V high current resistance MOS, which has long life and strong load capacity.
3. Use industrial grade LDO, resistant to high temperatures.
4. Use high-quality Japanese Murata capacitors with strong filtering performance.
5. Supports image transmission of ESC telemetry data.
6.LED: Supports external programmable LED lights.

Availability:

Quantity:



Inquire Add to Basket

Model:
F7220 32-bit AIO

Product Description

F722 32-bit 50A AIO Dual BEC 2-6S Flight Control Flying Machine Flight Control ESC Integrated FPV Drone

Product features:

1. The PCB uses high-end 8-layer 2oZ thickened copper skin, applies high-end resin plugged hole PCB production technology, and has a double pad design, which has stronger over-current capability and good heat dissipation.

2. MOS adopts imported 40V high current resistance MOS, which has long life and strong load capacity.
3. Use industrial grade LDO, resistant to high temperatures.
4. Use high-quality Japanese Murata capacitors with strong filtering performance.
5. Supports image transmission of ESC telemetry data.
6.LED: Supports external programmable LED lights.

Product specifications
		Flight control parameters
Size:	40* 30mm (20mm-20mm mounting hole)	CPU:	STM32F722RET6
Packing size:	646435mm	IMU:	ICM42688
Product net weight:	10g	OSD:	AT7456E
Packing weight:	54g	Barometer:	integrated
ESC parameters:		Black box:	16M
MOS model:	8010	BEC:	5V/2.5A
Continuous current:	50A	BEC:	10V/2A
Peak current:	60A	Sensor:	Built-in current sensor
Galvanometer scale value:	200	Flight control firmware version:	HAKRCF722D
Input voltage:	2S-6S Lipo	Receiver:	Frsky/ Futaba/ Flysky/ TBS Crossfire/ DSMX:DSM2 receiver
Firmware version:	HAKRC_AT4G_Multi_32_9.Hex
Protocol support:	PWM, Oneshot125， Oneshot42, Multishot, Dshot150， Dshot300， Dshot6
