F722 40A
Ø Product features:
1. The PCB uses high-end 8-layer 2oZ thickened copper skin, applies high-end resin plugged hole PCB production technology, and has a double pad design, which has stronger over-current capability and good heat dissipation.
2. MOS adopts imported 40V high current resistance MOS, which has long life and strong load capacity.
3. Use industrial grade LDO, resistant to high temperatures.
4. Use high-quality Japanese Murata capacitors with strong filtering performance
| Product specifications | ||||
| Flight control parameters | ||||
Size: | 32* 32mm (25.5mm-26.5mm mounting hole) | CPU: | STM32F722RET6 | |
Packing size: | 64*64*35mm | IMU: | ICM42688 | |
Product net weight: | 9g | OSD: | AT7456E | |
Packing weight: | 52g | Barometer: | integrated | |
ESC parameters: | Black box: | 16M | ||
Continuous current: | 40A | BEC: | 5V/2A | |
| Peak current: | 45A | Sensor: | Built-in current sensor | |
| Galvanometer scale value: | 210 | Flight control firmware version: | HAKRCF722D | |
| Input voltage: | 2S-6S Lipo | Parameter adjustment software | BLHeliSuite32Activator_32.9.0.3 | |
| Firmware version: | BLHELI_S (G-H-30) | Receiver: | CRSF/Frsky/ Futaba/ Flysky/ TBS Crossfire/ DSMX:DSM2 receiver | |
| Protocol support: | PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 | |||
