F722 BLHeli_32 45A AIO
Product features:
1. The PCB uses high-end 8-layer 2oZ thickened copper skin, applies high-end resin plugged hole PCB production technology, and has a double pad design, which has stronger over-current capability and good heat dissipation.
2. MOS adopts imported 40V high current resistance MOS, which has long life and strong load capacity.
3. Use industrial grade LDO, resistant to high temperatures.
4. Use high-quality Japanese Murata capacitors with strong filtering performance.
5. Support ESC telemetry data return.
6.LED: Supports external programmable LED light strips.
7. Dual gyroscopes reduce the error of one gyroscope.
| Product specifications | ||||
| Flight control parameters | ||||
Size: | 33* 33mm (25.5mm-26.5mm mounting hole) | CPU: | STM32F722RET6 | |
Packing size: | 64*64*35mm | IMU: | Dual gyroscope (ICM-42688) | |
Product net weight: | 8.5g | OSD: | AT7456E | |
Packing weight: | 54g | Barometer: | integrated | |
ESC parameters: | Black box: | 16M | ||
Continuous current: | 45A | BEC: | 5V/2A | |
| Peak current: | 55A | Sensor: | Built-in current sensor | |
| Galvanometer scale value: | 200 | Flight control firmware version: | HAKRCF722D | |
| Input voltage: | 2S-6S Lipo | Receiver: | CRSF/Frsky/ Futaba/ Flysky/ TBS Crossfire/ DSMX:DSM2 receiver | |
| Firmware version: | HAKRC_AT4G_Multi_32.9 Hex | |||
| Protocol support: | PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 | |||
