| Quantity: | |
|---|---|
Describe:
| Frame Model: | SPEED 5D/5X |
| Frame Wheelbase: | 220mm (5D) /215(5X) |
| StackInstallation Size: | 30.5mm*30.5mm/20mm*20mm |
| VTX: | 20mm*20mm(03Air Unit) |
| Camera Specifications: | 19mm/20mm |
| Motor Specifications: | 16mm*16mm |
| Fit Blade Specifications: | 4.9-5.1" |
| Roof Thickness: | 2.5mm |
| Baseplate Thickness: | 2mm |
| Center Plate Thickness: | 3mm |
| Dimension:2 | 231mm*202mm*53mm(5D)/202mm*199mm*53mm(5X) |
| Weight: | 138g(5D)/136g (5X) |
Product features:
Metal CNC camera mount
Ultra-light injection molded colorful protective case
Air duct design, improve the heat dissipation effect
Convenient parameter adjustment side panel, one-key remova
Innovative TPU shock absorption structure
Multi-layer fuelinjection+ chamfering design
Front-out/rear-out power cables to meet a variety of battery placement needs
product list
Frame bag:
2.5mm Roof (5D) *1 / 2mm Roof (5X)
2mm Bottom Plate (5D) *1 / 2.5mm Bottom Plate (5X)
5mm Arm*4
3mm Center Plate*1
2.5mm Arm limit plate*1
2mm Camera fixed side panel*2
Screw Pack:
M3*28Aluminum Column*8
M5*20 Bolt*1
M5 Dome Head Nut*1
M3*28 Pan Head Screws*4
M2 Nut*4
M2*18 Pan Head Black Nickel Plated Screws*4
M3*8 Pan Head Black Nickel Plated Screws*4
M3*6 Pan Head Black Nickel Plated Screws*10
M3*10 Pan Head Black Nickel Plated Screws*24
M1.6*8 Flat Head Black Nickel Plated Screw*4
3D Printing Accessories:
VTXAntenna GPS915 Mount*1
Arm Limiter Plate Stabilizer*1
UniversalGoPro Mount*1
Camera Mount*2
Buzzer Printout*1
Receiver Printout*1
