Product name: GOPRO3/GOPRO4CNC metal brushless 3-axis gimbal.



Motor model: 2206/100T brushless motor: 2 pieces, 2805/100T brushless motor: 1 piece



Driver board: STORM32BGC

Firmware version: o323bgc-release-v090

Hardware version: V130

Working voltage: 3-4S (11.1-16.8V)

Working current: 350mA

Joystick control angle: PITCH: -25 degrees + 25 degrees / ROLL: -25 degrees + 25 degrees / YAW: -90 degrees + 90 degrees.

Switch control mode: lock/follow

Product name: BGC 3.1 high current 2-axis brushless gimbal control board

Manufacturer number: BGC30P

Product shape: 50*50*10mm

Driving mode: MOS tube

Storm 32-bit lightweight three-axis brushless gimbal

Motor: 1 hollow shaft motor 2805 160KV

Hollow shaft motor 2206 160KV 2 Storm32-bit control boards, main control chip STM32F103; PTZ parameters: voltage 11.1~16.8V (3S/4S lithium battery); current 350mA; total weight 308G; net weight 180G, size 8*8*8 ~11(cm)





Optional power connectors: JST and XH



Accessories: some straps and screws

The tilt camera adopts a one-piece structure. Through excellent shape structure design and advanced manufacturing technology, a more professional five-lens camera is created. It is equipped with a professional fixed-focus surveying and mapping lens as standard. The total pixels are up to 120 million, and the housing is tilted forward by 8°. The fixed inclination angle makes the attitude data more accurate;

This drone frame is equipped with an ultra-light injection molded protective cover, which can improve heat dissipation and has a one click disassembly function





The front/rear power cord of this drone frame can meet various battery placement needs, and is equipped with a metal CNC camera bracket
